Real-time analytics of Internet traffic flow data

Download the dataset

• The full preprocessed dataset is hosted here - 1.4GB
• Place this file in the preprocessing directory
• For testing purposes, you can use the sample CSV that has 10k records from each day instead, change the bind path in the Compose file

To run the project

• From the scripts directory:
  • Run deploy.ps1 -M for Windows
  • Run deploy.sh -M for Linux/macOS (add -S if sudo needed for docker)
  • See the README in scripts for more
• This sets up the whole stack

Access the UI

• The Grafana web interface is located at http://localhost:7602
• Login:
  • Username: thewebfarm
  • Password: mrafbeweht
• Go to Dashboards > Internet traffic capture analysis

To run the shard creation and scaling script

• From the scripts directory:
  • Install dependencies: python3 -r ../clickhouse/update_config_scripts/requirements.txt
  • Run python3 ../clickhouse/update_config_scripts/update_trigger.py
• This checks every 2 minutes and creates a new shard and two server nodes for it based on resource utilization

Limitations

• For multi-node deployments using Docker Swarm, the manager node needs to be running on Linux (outside Docker Desktop i.e. standalone Docker installation) due to limitations in the Docker Swarm engine
